EWP 3500

Category: 1000-4500 lbs, ATV&UTV Winch, Electric Winch, EWP Series

Features:

  • Full steel gear reducer
  • Runva patent cam cluth
  • Self-lock braking action
  • High current switch control directly
  • Wireless remote control available
  • DC 12v or DC 24v Power drive optional

Inquiry

    Share:

    Previous
    EWX 3000
    Next
    EWP 4500

    SPECIFICATIONS

    Rated line pull 3500 lbs (1588 kgs)
    Motor:permanent magnet 12V:Input:2.4kW/3.2hp;Output:1.0kW/1.3hp
    24V:Input:2.9kW/3.9hp;Output:1.2kW/1.6hp
    Brake Self-lock
    Geartrain Full steel
    Gear reduction ratio 170:1
    Clutch Cam
    Cable(Dia×L) Ø7/32″×42.0’(Ø5.4mm×12.8m)
    Drum size(Dia×L) Ø1.46″×3.15″(Ø37mm×80mm)
    Mounting bolt pattern 4.9″x3″(124mmx76mm);4-M8
    Net weight 22.0lbs/10.0kgs

    DIMENSIONS

    12V DC PERFORMANCE SPECS (first layer)
    Line Pull Line Speed Motor Pull by layer
    Lbs.(kgs) Ft/min.
    (M/min.)
    Current layer/Lbs.(kgs)
    0 10.2(3.1) 20amps 2/2789(1265)
    1000 (454) 8.9(2.7) 75amps 3/2319(1052)
    2000 (907) 7.5(2.3) 130amps 4/1984(900)
    3500 (1588) 4.6(1.4) 200amps 5/1733(786)
